Portable Oxygen Concentrator
JAY-1
JAY-1
JAY2/3
JAY-1000
JAY-2000P
Our portable oxygen concentrator whose oxygen output is1-5L/min is small and light. Therefore, it is quite suitable for mobile use. Combined with an adaptor for vehicle, this oxygen producing machine can be amounted on automobiles. This is a cost-effective product appropriate for blue-and-white collar workers and the common masses.
1. This portable oxygen concentrator offers a great outdoor oxygen supply solution for patients who have to go out for a short time.
2. This portable oxygen concentrator can be used to cure headache and sleep apnea syndrome caused by cervical spondylosis.
3. Inhaling oxygen with this oxygen gas generator will help white-collar workers and students to regain energy.
4. This portable oxygen concentrating equipment is available for home health care of pregnant women or old people.
5. It helps relieve discomfort caused by haze.
6.suitable for oxygen cocktail making.
JAY-1
The concentration of the oxygen produced by our product is adjustable within the range of 38% -93%. When producing oxygen with concentration of 93% and flow rate of 1L/min, this portable oxygen generation plant is suitable for people who need to inhale high-concentration low-flow oxygen, such as patients with carbon dioxide retention.
When producing oxygen having concentration of 38% and flow rate of 5L/min, our portable oxygen concentrator is appropriate for people who need to inhale low-concentration high-flow oxygen, for example, athletes.
Technical Parameter| Model | JAY-1 |
| 1.Oxygen Flow (L/min) | 1-5 |
| 2.Oxygen Concentration (%) | 90-30 |
| 3.Oxygen Pressure (Mpa) | 0.03-0.07 |
| 4.Noise (dB) | ≤45 |
| 5.Dimension(mm) | 350×190×320 |
| 6.N.W. (kg) | 6 |
| 7.Rated Power (W) | ≤75 |
| 8.Power Supply(V) | AC220V/110V; |
| 9.Options | DC12V; Trolley bag; Strapped bag |
JAY-2/3
Application
JAY-2: Designed for infants, the flow rate is 0-2L and the minimum scale can reach 0.125L/min.
JAY-3: The flow rate is 0-3L. Used for homecare and health care.
| Flow Rate | 0-2LPM | 0-3LPM |
| Purity | 93% (±3% ) | |
| Outlet Pressure | 0.04-0.07MPA (6-10PSI) | |
| Sound Level | ≤45dB | |
| Power Consumption | ≤200VA | ≤250VA |
| LCD Display | Present working time, accumulated working time | |
| Alarm | Power Failure alarm, Low purity alarm (Optional) | |
| Net Weight | 11kg | 12kg |
| Size | 435*240*410mm | |
JAY-1000
Feature:
Oxygen purity is 93±3%, 4 settings for different needs.
The 1-3 setting pulse oxygen supply mode is to deliver O₂ based on breathing rate, O₂ utilization rate is 100%, so it is equal to 1-3L oxygen concentrator. In the case of unable to detect the breathing rate, it will automatically jump to setting 4, automatically and continuously supply oxygen, and the continuous flow rate is 1000ml/min.
| Flow Setting | 1000 ml/min(continous flow) | 1/2/3/4 (continous flow) |
| Pulse Flow Rate (ml/pulse) | / | 15/30/45/1000 (ml/min) |
| Power Consumption (w) | 85 | |
| Battery Duration Time (hours) | 1 | |
| Sound Level (dB) | ≤45 | |
| Net Weight(KGS) | 6 | |
| Size(mm) | 350×190×320mm | |
JAY-2000P
Feature:
Oxygen purity is 93±3%, 6 settings for different needs.
1-5 setting pulse oxygen supply mode is to deliver O₂ based on breathing rate, O₂ utilization rate is 100%, so it is equal to 1-5L oxygen concentrator. In the case of unable to detect the breathing rate, JAY-2000P oxygen concentrator will automatically change to setting 6 with the rate of 20 pulse / min.
| Flow Setting | 1/2/3 (Mode A) | 1/2/3/4/5/6(Mode B) |
| Pulse Flow Rate(ml/min) | 360/650/950 | 350/500/650/800/1000/650 |
| Power Consumption(w) | 40/50/70 | 40/45/50/60/70/50 |
| Battery Duration Time(hours) | 1/2/3/4/5/6 | 4/3.5/3/2.5/2/3 |
| Sound Level(dB) | ≤45 | |
| Net Weight(KGS) | 4 | |
| Size(mm) | 350×190×320 | |
